Meggitt VM600 User Manual

VM600 networking manual MAVM600-NET/E E - 1
Edition 9 - February 2018
APPENDIX E: SYMBOL NAMES
APPENDIX E: SYMBOL NAMES
A list of symbol names (that is, text description tags) has been defined for the MPC4 and
AMC8 cards. This list is available from Meggitt Sensing Systems as a text file, on request.
This information can be used with the SIMATIC STEP 7 software, as Symbols, to make the
data available at each PROFINET address easier to identify and understand.
NOTE: In the following table, n (in the Symbol name column) defines the VM600 rack slot
number for a card, which can be from 3 to 14.
Table E-1: Reserved words (Symbol names)
Symbol
name
(n is a slot
number from
3 to 14)
MPS backplane
configuration extractor
tools syntax
Logical
inv.
Normal
state
Function, as described in the
VM600 MPSx software
MPC
Common
nMCR Slot n (MCR) 0 1 Common MPC Diagnostics MPC Card Running
nCMF Slot n (CMF) 0 0 Common MPC Diagnostics Monitoring Failure
nCOF Slot n (COF) 0 0 Common Channels Sensor OK Failure
nCPE Slot n (CPE) 0 0 Common MPC Diagnostics Processing Error
nCIE Slot n (CIE) 0 0 Common Signal Diagnostics Input Signal Error
nCA Slot n (CA) 0 0 Common Channels Alarm
nCD Slot n (CD) 0 0 Common Channels Danger
nCSOL Slot n (CSOL) 0 0 Common Trk/Spd Diagnostics Speed Out Of Limit
nCTL Slot n (CTL) 0 0 Common Trk/Spd Diagnostics Track Lost
nCTOR Slot n (CTOR) 0 0 Common Trk/Spd Diagnostics Track Out Of Range
nCDSE Slot n (CDSE) 0 0 Common MPC Diagnostics DSP Saturation Error
nCISE Slot n (CISE) 0 0 Common Signal Diagnostics Input Saturation Error
nCCME Slot n (CCME) 0 0 Common Signal Diagnostics Common Mode Overflow
nSL Slot n (SL) 0 0 Common MPC Diagnostics Status Latch/Err.
nDTM Slot n (DTM) 0 0 Common Controls Direct Trip Multiply
nDBP Slot n (DBP) 0 0 Common Controls Danger Bypass
nAR Slot n (AR) 0 0 Common Controls Alarm Reset
MPC
Speed channels
nS1A+ Slot n (S1A+) 0 0 Speed Channel 1 Alarm + High
nS1A- Slot n (nS1A-) 0 0 Speed Channel 1 Alarm – Low
nS1ERR Slot n (nS1ERR) 0 0 Speed Channel 1 Invalid
nS1SOK Slot n (nS1SOK) 0 1 Speed Channel 1 Sensor OK check successful (SOK
nS2A+ Slot n (nS2A+) 0 0 Speed Channel 2 Alarm + High
nS2A- Slot n (nS2A-) 0 0 Speed Channel 2 Alarm - Low
nS2ERR Slot n (nS2ERR) 0 0 Speed Channel 2 Invalid
nS2SOK Slot n (nS2SOK) 0 1 Speed Channel 2 Sensor OK check successful (SOK
