APPENDIX E: SYMBOL NAMES
MPC
Measurement Channel 1
nV11A+ Slot n (V11A+) 0 0 Measurement Channel 1 Process Output 1 A+
nV11A- Slot n (V11A-) 0 0 Measurement Channel 1 Process Output 1 A-
nV11D+ Slot n (V11D+) 0 0 Measurement Channel 1 Process Output 1 D+
nV11D- Slot n (V11D-) 0 0 Measurement Channel 1 Process Output 1 D-
nV11ERR Slot n (V11ERR) 0 0 Measurement Channel 1 Process Output 1 Error bit
nV12A+ Slot n (V12A+) 0 0 Measurement Channel 1 Process Output 2 A+
nV12A- Slot n (V12A-) 0 0 Measurement Channel 1 Process Output 2 A-
nV12D+ Slot n (V12D+) 0 0 Measurement Channel 1 Process Output 2 D+
nV12D- Slot n (V12D-) 0 0 Measurement Channel 1 Process Output 2 D-
nV12ERR Slot n (V12ERR) 0 0 Measurement Channel 1 Process Output 2 Error bit
nV1PGA Slot n (V1PGA) 0 0 Measurement Channel 1 PGA Saturation Error
nV1SOK Slot n (V1SOK) 0 1 Measurement Channel 1 Sensor OK check successful
MPC
Measurement Channel 2
nV21A+ Slot n (V21A+) 0 0 Measurement Channel 2 Process Output 1 A+
nV21A- Slot n (V21A-) 0 0 Measurement Channel 2 Process Output 1 A-
nV21D+ Slot n (V21D+) 0 0 Measurement Channel 2 Process Output 1 D+
nV21D- Slot n (V21D-) 0 0 Measurement Channel 2 Process Output 1 D-
nV21ERR Slot n (V21ERR) 0 0 Measurement Channel 2 Process Output 1 Error bit
nV22A+ Slot n (V22A+) 0 0 Measurement Channel 2 Process Output 2 A+
nV22A- Slot n (V22A-) 0 0 Measurement Channel 2 Process Output 2 A-
nV22D+ Slot n (V22D+) 0 0 Measurement Channel 2 Process Output 2 D+
nV22D- Slot n (V22D-) 0 0 Measurement Channel 2 Process Output 2 D-
nV22ERR Slot n (V22ERR) 0 0 Measurement Channel 2 Process Output 2 Error bit
nV2PGA Slot n (V2PGA) 0 0 Measurement Channel 2 PGA Saturation Error
nV2SOK Slot n (V2SOK) 0 1 Measurement Channel 2 Sensor OK check successful
MPC
Measurement Channel 3
nV31A+ Slot n (V31A+) 0 0 Measurement Channel 3 Process Output 1 A+
nV31A- Slot n (V31A-) 0 0 Measurement Channel 3 Process Output 1 A-
nV31D+ Slot n (V31D+) 0 0 Measurement Channel 3 Process Output 1 D+
nV31D- Slot n (V31D-) 0 0 Measurement Channel 3 Process Output 1 D-
nV31ERR Slot n (V31ERR) 0 0 Measurement Channel 3 Process Output 1 Error bit
nV32A+ Slot n (V32A+) 0 0 Measurement Channel 3 Process Output 2 A+
nV32A- Slot n (V32A-) 0 0 Measurement Channel 3 Process Output 2 A-
nV32D+ Slot n (V32D+) 0 0 Measurement Channel 3 Process Output 2 D+
nV32D- Slot n (V32D-) 0 0 Measurement Channel 3 Process Output 2 D-
nV32ERR Slot n (V32ERR) 0 0 Measurement Channel 3 Process Output 2 Error bit
nV3PGA Slot n (V3PGA) 0 0 Measurement Channel 3 PGA Saturation Error
nV3SOK Slot n (V3SOK) 0 1 Measurement Channel 3 Sensor OK check successful
Table E-1: Reserved words (Symbol names)
Symbol
name
(n is a slot
number from
3 to 14)
MPS backplane
configuration extractor
tools syntax
Logical
inv.
Normal
state
Function, as described in the
VM600 MPSx software
