Mercury VesselView User Manual

Section 2 - Setup and Calibration
90-8M0070299 eng MAY 2012 Page 19
Method 1: Default
1. On the "TANK CALIBRATION" screen, press the check button to choose the "DEFAULT" calibration method. VesselView
displays a saving settings message.
2. Repeat the tank calibration process for any additional tanks.
Method 2: Manual
1.
On the "TANK CALIBRATION" screen, press the "X" button to choose the "MANUAL" calibration method.
2. Ensure the tank is empty. Press the check button to confirm.
3. Following the direction on the screen, fill the tank to 25% of its capacity. Press the check button to confirm, or the back
button to go back one step.
4. Following the direction on the screen, fill the tank to 50% of its capacity. Press the check button to confirm, or the back
button to go back one step.
5. Following the direction on the screen, fill the tank to 75% of its capacity. Press the check button to confirm, or the back
button to go back one step.
6. Following the direction on the screen, fill the tank to 100% of its capacity. Press the check button to confirm, or the back
button to go back one step.

Mercury VesselView Specifications

General

Display Type	LCD
Touchscreen	Yes
Power Supply	12V DC
Waterproof Rating	IPX7
Connectivity	NMEA 2000, Bluetooth
GPS	Yes
Alarms	Yes
Resolution	800 x 480 pixels
Mounting Type	Flush mount
Data Displayed	Engine data, fuel usage, GPS
