Section 5 - Propulsion Menu
Page 78 90-8M0070299 eng MAY 2012
Viewing Peak Performance
The peak performance screen shows current speed and RPM, as well as the highest speed and associated engine RPM
recorded since the last reset.
a - Actual engine RPM
b - Actual boat speed
c - Peak engine RPM
d - Peak boat speed
• RPM is displayed for up to three gas or diesel engines.
• Speed is displayed using pitot, paddle, or GPS sensor information.
• Peak speed is the highest speed recorded since the last reset of peak values.
• Peak engine RPM is the engine RPM associated with the highest speed since the last reset of peak values.
Resetting Peak Values
1. Press the check button while on this screen to access the "peak values" pop‑up screen. The pop‑up will ask you "Would
you like to Reset your Peak Values?"
Would you like to Reset
your Peak Values?
27243
Peak values pop-up screen
2.
Press the check button to reset the peak values or the "X" button to cancel.
Viewing Steering Position (MerCruiser Only)
The "STEERING POSITION" screen displays the current steering position in degrees. The default steering position can be
adjusted 60 degrees in either direction by changing the offset. The data options on the bottom of the screen can be changed to
display different data. Refer to Section 4 ‑ Settings for more information.
