Section 4 - Main Menu
Page 58 90-8M0070299 eng MAY 2012
Page/Screen Favorites
VesselView also enables a user to specify what screens in each of the three categories they want to have as favorites. Each
page selected as a favorite will have a heart shape icon. Each page selected as a favorite will flash on the screen for a specific
amount of time and will also be available when changing to the "Propulsion," "Vessel," or "Environment" category. The time
duration is programmable from 5 to 20 seconds in the "PREFERENCES" menu.
a - Selected favorites
b - Selected pages on
c - Not selected
Trim Setting
The "TRIM SETTING" turns the trim pop‑up window on or off, sets the amount of time the pop‑up remains on the screen, and
adjusts the trim filter. A high filter setting requires the trim to be moved farther before the pop‑up window turns on. The menu
path is: "Main" > "Settings" > "Screen Option" > "Trim Setting."
a - Trim pop‑up window activation
b - Trim pop‑up window time
c - Trim filter
1. Upon entering the "TRIM SETTING" the "TRIM POPUP" will be highlighted in blue.
2. Press the left or right arrow to turn the trim pop‑up window on or off.
3. Press the down arrow to highlight the "POPUP TIME."
4. Press the left or right arrow to change the amount of time the trim pop‑up window remains on the screen from two seconds
("2 sec") to 60 seconds ("60 sec").
5. Press the down arrow to highlight the "TRIM DELTA %."
6. Press the left or right arrow to adjust the percentage of travel the engine or drive must move before the trim pop‑up will
appear. The percent range is from 0.1 to 9.9. In addition to the delta percent adjustment is "USE TRIM FLAG" option.
37108
TRIM SETTING
TRIM POPUP
POPUP TIME
TRIM DELTA %
ON
2 sec
0.5
a
b
c
To Next Page
