Mercury VesselView User Manual

Section 3 - Screen Overview and Operation
90-8M0070299 eng MAY 2012 Page 33
MerCruiser Display Screens
Screen
Category
Menu Screen
Gas
Sterndrive
No Troll
Gas
Inboard
No Troll
Gas
Sterndrive
Gas
Inboard
Diesel
Sterndrive
No Troll
Diesel
Inboard
No Troll
Diesel
Sterndrive
Diesel
Inboard
Propulsion
Engine Status
X X X X X X X X
Performance
and Fuel
X X X X X X X X
Steering
Position
X X X X X X X X
Peak
Performance
X X X X
Trim
X X
Tab
X X X X X X X X
Demand and
Load
X X X X
Boost
Menu option
Troll Control
X X X X
Cruise Control
Option (DTS only)
Smart Tow
Option (DTS only)
Transmission
X X X X
Intake
X X X X
Vessel
Vessel Status
X X X X X X X X
Tank Status
X X X X X X X X
Generator
X X X X X X X X
Steering
Position
X X X X X X X X
Environment
and
Navigation
Depth
X X X X X X X X
Trip Log
X X X X X X X X
Fuel to
Waypoint
GPS only
Navigation
GPS only
Autopilot
(Zeus and
Axius only)
Axius only X Axius only
Joystick (Zeus
and Axius
only)
Axius only X Axius only
Skyhook
(Zeus and
Axius only)
Axius only X Axius only

Mercury VesselView Specifications

General

Display Type	LCD
Touchscreen	Yes
Power Supply	12V DC
Waterproof Rating	IPX7
Connectivity	NMEA 2000, Bluetooth
GPS	Yes
Alarms	Yes
Resolution	800 x 480 pixels
Mounting Type	Flush mount
Data Displayed	Engine data, fuel usage, GPS
