Section 4 - Main Menu
90-8M0070299 eng MAY 2012 Page 55
Factory Reset Menu
The "Factory Reset" menu is used to reset all VesselView settings to the factory default, or to perform a sensor detection.
When the VesselView is first configured during the setup wizard, the system will automatically detect sensors that are present
and ignores sensor inputs that have no sensors attached. If a sensor is removed from the system after the initial configuration,
VesselView will show faults for the removed sensor. VesselView will scan for sensors and eliminate the fault message.
Save Configs Menu
After the system has been completely configured, the "SAVE CONFIGURATION" option exports (saves) all configuration
settings to a USB memory stick for use with other VesselView units or for quick recovery of stored configuration settings. This
saves time by importing a configuration without having to complete the entire setup wizard and other calibrations.
IMPORTANT: The VesselView unit will recognize USB memory sticks of version 1.1 or a USB memory stick of version 2.0 that
is stated to be backwards compatible to version 1.1. The VesselView unit will not recognize memory sticks that are only version
2.0 compatible.
IMPORTANT: Configuration settings saved to a USB memory stick are compiled into one data file. Only one file can exist in the
root of the USB memory stick. VesselView will not recognize multiple import files.
Load Configs Menu
After a configuration file was exported to the USB memory stick, the "LOAD CONFIGURATION" menu imports the configuration
settings into another VesselView unit.
Settings
Settings Menu Options
IMPORTANT: The available VesselView menu items and options are dependent on the engine type, and if screens have been
manually turned on or off.
The "Settings" menu enables you to customize VesselView. The "Settings" menu items include the following:
47863
Setup
Calibrate
Settings
Alarms
System Info
Main
Favorites
Settings
Screen Options
Clock/Light
Preferences
Boat Speed
Warnings
Units
Units 2
Offsets
Screen Optio.
Status bar
Steering
Trim Settings
Tab Settings
Autopilot
Screen Optio.
Status bar
Steering
Autopilot
Screen Optio.
Status bar
Steering
Trim Settings
Tab Settings
Pages On/Off
Settings
Alarms
System Info
Maintenance
Calibrate
Autopilot
Engine Status
NOTE: After any change or customization to the VesselView configuration, a blue pop‑up message will appear as a reminder to
save the session. It is recommended that all session changes be saved before holding the "
X
" button while keying all engines
off. Refer to
Section 1
‑
Saving the Settings
.
