Section 3 - Screen Overview and Operation
90-8M0070299 eng MAY 2012 Page 41
Menu Option Description Screen
Tabs
Configures the propulsion type and number of tabs.
PROPULSION TYPE
MERCURY
45146
TABS
NUMBER OF TABS
2
RIGHT TAB
STBD TAB 1
LEFT TAB
PORT TAB 2
Trim
Sets the engine trim levels.
27222
Configuration
Assigns VesselView location, number of engines, and the data
display location.
27125
Factory Reset
Resets all VesselView settings to factory default. Can also reset
just the engine sensor detection to factory default.
34385
Save Configs
Saves selected configuration data to a memory stick.
SAVE CONFIGURATION
TANK CONFIG
TRIM CONFIG
DEPTH CONFIGS
UNITS/APP PREF
STEERING
EXPORT
EXPORT
EXPORT
EXPORT
EXPORT
27235
