Handling of Consumables 49
_________________________________________________________________________________________
_________________________________________________________________________________________
Microplex logiJET TC8 Edition 1.2
Fig. 5.2.2.f Winding the end of the ribbon
11. Use
supply shaft with the new ribbon) and use your left hand to
takeup core). The end of ribbon between the two mandrels
should be about 300 mm (compare figure above).
12. Lead the free end of ribbon around the printhead (take care
that the ribbon has no wrinkles).
Fig. 5.2.2.g Leading the ribbon around the printhead
