QX-830 Compact Industrial Scanner User’s Manual 1-1
1 Quick Start
Contents
This section explains how to set up and test the QX-830 quickly using ESP (Easy Setup Program).
Detailed setup information for installing the scanner into an application can be found in
subsequent sections.
Step 1 Check Hardware................................................................................................................1-2
Step 2 Connect the System ..........................................................................................................1-3
Step 3 Position Scanner and Symbol ...........................................................................................1-4
Step 4 Install ESP.........................................................................................................................1-5
Step 5 Select Model......................................................................................................................1-6
Step 6 Connect .............................................................................................................................1-7
Step 7 Test Read Rate .............................................................................................................. 1-10
Step 8 Configure the Scanner.................................................................................................... 1-11
Step 9 Save Changes in ESP.................................................................................................... 1-12
