Microscan QX-830 - Appendix B Electrical Specifications

A-6 QX-830 Compact Industrial Scanner User’s Manual
Electrical Specifications
Appendix B — Electrical Specifications
QX-830 Connectors
Power Requirement
7.5 Watts (max.) at 28VDC, 10-28VDC, 200 mV p-p max. ripple,
180mA at 24VDC (typ.)
9 RS-232 RxD 9
RS-232 TxD/RS-232 RTS
10 RS-232 TxD 10 RS-232 RxD/RS-232 CTS
2 Power 2 Power
7 Ground 7 Ground
1 Trigger 1 Trigger
8 Input Common 8 Input Common
3 Default 3 Terminated
4 New Master 4 Input 1
5 Output 1 5 RS-422/485 TxD (+)
11 Output 2 11 RS-422/485 TxD (–)
6 Output 3 6 RS-422/485 RxD (+)
12 Output Common 12 RS-422/485 RxD (–)
Ground
Output 3
Output 1
Output 2
New Master
Default
Power
Input Common
Output Common
RS-232 RxD
Trigger
RS-232
TxD
Connector A (Serial)
M12 12-pin Plug
Input
Common
RS-422/485 RxD (–)
RS-232 TxD/RS-232 RTS
Trigger
RS-232 RxD/RS-232 CTS
Power
Ground
RS-422/485
RxD (+)
RS-422/485
TxD (+)
RS-422/485 TxD (–)
Input 1
Termina ted
Connector B (Serial)
M12 12-pin Socket
TX (+)
RX (–)
RX (+)
TX (–)
Termin ated
Termin ated
Connector B (Ethernet)
M12 8-pin Socket
Termin ated
Terminated
1 Terminated
2 Terminated
3 Terminated
4 TX (–)
5 RX (+)
6 TX (+)
7 Terminated
8 RX (–)
