TM80 Telemetry Monitor Service Manual A-7
WARNING
If all of the applied parts correspond to the instrument type, the
applied parts will be tied together and one reading will be taken. If any
of the applied parts differ from the instrument type, all applied parts
will be tested individually, based on the type of applied part. This
applies to Auto and Step modes only.
To Perform the Test
1. From the MAIN MENU, or with the outlet unpowered, plug the DUT into the
601PRO front panel outlet, and turn on the device.
2. Attach the applied parts to the 601PRO's applied part terminals.
3. Press shortcut key 6. The Patient Leakage test is displayed, and the test begins
immediately.
4. Press APPLIED PART (SOFT KEY 4) at any time to select the desired applied part
leakage current.
5. Modify the configuration of the front panel outlet by pressing the appropriate
SOFT KEY on the 601PRO.
6. Press the print data key at any time to generate a printout of the latest
measurement.
