TM80 Telemetry Monitor Service Manual 7-17
Symptom Possible cause Solution
The TM80 and
BP10 are prone
to offline in
certain area.
As there are many Wi-Fi
devices in this area,
communication between
the TM80 and BP10 is
interfered seriously.
Contact your service personnel.
Some TM80 or
BP10 is prone
to offline.
Device malfunction Use other monitors to confirm the
fault. If only monitor is faulty, return
the monitor for repair.
7.4 Error Codes
Error code Description
001 Module Selftest Err(0xff)
002 ECG ASIC Init Err
003 ECG ASIC 3.3V Err
004 SPO2 Init Err
006 MPANInit Err
008 Battery Comm Err
011 Power 2.5V Err(0xff)
013 SPO2 Selftest: AFE4490
014 SPO2 Selftest: CPU
015 SPO2 Selftest: FLASH
016 SPO2 Selftest: POWER
017 SPO2 Selftest: RAM
018 SPO2 Selftest: WATCHDOG
