Mindray BeneVision TM80 Service Manual

TM80 Telemetry Monitor Service Manual 2-3
The following figure shows relationships among the subsystems.
Telemetry
Monitoring
system
Transmission
system
AP array
CMS
Receive data
Data analysis
Data management
Information display
Collect and upload ECG/SpO2/
NIBP/RESP parameters
Local alarm
Local storage and review
Upload data
2.3.1 Module Configurations for the TM80 Telemetry Monitor
The table below shows the ECG, Resp, SpO
2
, and NIBP configuration status for the
TM80 Telemetry Monitor.
Parameter Standard Optional
ECG Yes /
Resp / Yes
SpO
2
/ Yes
NIBP / Yes

Mindray BeneVision TM80 Specifications

General

Brand	Mindray
Model	BeneVision TM80
Category	Monitor
Language	English
