TM80 Telemetry Monitor Service Manual A-15

For the central charger

Repair with main unit not disassembled

Test items: 1, 2, 3

Repair with main

unit disassembled

When power supply

PCBA is repaired or

replaced

Test items: 1, 2, 3, 4,

A.11 Electrical Safety Inspection Form

For the TM80

Inspection and Testing Limit

1 Device Enclosure and Accessories /

2 Device Labeling /

3 Patient

Leakage

Current

Normal condition (NC) Max:

CF applied part:

NC:10μA, SFC: 50μA

BF applied part:

NC:100μA, SFC: 500μA

Single Fault condition

(SFC)

4 Mains on Applied Part Leakage Max:

CF applied part: 50μA

BF applied part: 5000μA

5 Patient

Auxiliary
