TM80 Telemetry Monitor Service Manual 5-11
5.5.2 Power-On Test
This test is to verify that the TM80 can be powered on correctly. Follow this
procedure to perform the test:
1. Install a lithium-ion rechargeable battery pack or AA batteries into the device’s
battery compartment.
2. The TM80 will be powered on automatically. The alarm light will momentarily
illuminate cyan to indicate that the equipment is starting.
3. The boot screen appears, the TM80 sounds a beep, and its alarm light flashes
red, yellow, and cyan in turn, and then turns off. This indicates that the alarm
system functions correctly.
4. When the boot screen disappears, the main screen displays and the device
finishes starting.
5.5.3 Nurse Call Test
Follow this procedure to perform the test:
1. Press the nurse call button on the device.
2. Observe corresponding display on the central station. If a nurse call icon
appears, it indicates that the nurse call test passes.
5.5.4 Electric Safety Test
Refer to AElectrical Safety Inspection.
