Operator’s Manual 18 - 1
18 DVR Recording
NOTE:
• Strictly observe the procedures described here to perform the recording and replaying
operations; otherwise it may result in data loss or system malfunction.
• Set the PAL or NTSC in the setup and this shall be consistent with that in the DVR.
• Accidental exposure to strong electromagnetic fields or mishandling of the video cassette may
result in image and data loss, so check if the recording is successful as soon as possible.
Mindray is not responsible for any data loss.
The system provides built-in DVR recording function. You can use the DVR to record and replay
videos and audios that can be stored in DVD disc or hard disc.
The recorded video is AVI format; you can save it in the hard disk drive, burn to the DVD or export
to the USB disk.
When the built-in DVR is in normal status, the displays at the lower right corner of the screen.
18.1 Start Recording
After recording, the system will save the recording file automatically, you can select to save in local
disk, U disk or optical disk.
1. Perform ultrasound exams, select appropriate views and adjust parameters to prepare for
recording.
2. Click to open the dialog box and select desired recording type: Hard disk/USB/CDROM.
3. Click [Close] to enter recording status.
4. Press <F9> to record, and the DVR icon displays as in recording status.
During the recording process, you can perform imaging mode switching, comments adding,
body mark adding and measurements.
5. Press <F9> again to stop recording, the DVR icon in the lower right corner turns into data
transfer status .
– If USB/CDROM is selected, the system sends the recorded file to the target storage media
(USB disk or DVD optical disk drive) in the meantime.
– If “Hard disk” is selected, the system saves the file to the path: D/LV/DVR.
In the task management screen, click [Media Storage Task] tab to check transferring status.
18.2 Send Image
The system also supports exporting recorded images that are saved in the local disk.
1. Click to open the dialog box, and click [Local Video Manage] to enter the managing dialog
box.
Click [Rename] to rename the video file.
