A Barcode Reader
Operator’s Manual A - 5
decoding difficult. You can tilt the reader up to 55° forward or back and achieve a successful
decode.
A.1.4 Scanning in Hands-Free Mode
Assembling the Intellistand
Perform the following procedure:
1. Unscrew the wingnut from the bottom of the one piece scanner “cup”.
2. Fit the bottom of the neck piece into the opening on the top of the stand base.
3. Tighten the wingnut underneath the base to secure the cup and neck piece to the base.
Before tightening the wingnut under the base, ensure that the flat areas on the flexible neck fit
securely in the grooves in the base.
4. Bend the neck to the desired position for scanning.
1 One piece scanner “cup” with flexible
neck
2 Flat areas
3 Stand base 4 Wingnut
1
2
3
4
