A - 6 Operator’s Manual
A Barcode Reader
Mounting the Stand (optional)
You can attach the base of the reader’s stand to a flat surface using two screws or double-sided tape
(not provided).
Perform Scanning in Hands-Free Mode
When the reader is seated in the scanner cup, the reader’s built-in sensor places the reader in hands-
free mode. When you remove the reader from the stand it operates in its normal hand-held mode.
1 Two screw-mount holes For Screw Mount, follow the steps below:
1. Position the assembled base on a flat surface.
2. Screw one #10 wood screw into each screw-mount
hole until the base of the stand is secure
2 Double-side tap areas
(3 places, dimensions: 1”×2”)
For Tape Mount, follow the steps below:
1. Peel the paper liner off one side of each piece of
tape and place the sticky surface over each of the
three rectangular tape holders.
2. Peel the paper liner off the exposed sides of each
piece of tape and press the stand on a flat surface
until it is secure.
