12 - 26 Operator’s Manual
12 Probes and Biopsy
4. Release the needle from the bracket:
a. Screw the nut of the guiding block and remove the guiding block slightly along the
direction of the needle’s tail.
b. Separate the residual part of the needle-guide bracket and the probe from the needle.
5. Remove the needle-guided bracket:
a. Unscrew the Needle-guided bracket pinch nut, and remove the needle-guided bracket
from the probe.
b. Separate the probe and the needle-guided bracket.
NGB-007 Plastic/needle detachable needle-guided bracket
1 Support of needle-guided bracket
2 Angle block
