Mindray Z6 Service Manual

2-4 Product Specifications
No.
Name
Description
Function
1
/
Power button
Off: when system is turned off;
Green: when system is turned on by pressing this
button;
Orange: when system is in standby.
2
Esc
Exit
Press to exit the current status to the previous status.
3
Help
/
Press to open or close the accompanying help
documents.
4
Patient
Patient
Information
Press to open/ exit patient information screen.
5
Probe
Probe switch
Press to switch Probe and Exam Type
6
Review
/
Press to review the stored images.
7
Report
/
Press to open or close the diagnosis reports.
8
End Exam
/
Press to end an exam.
9
iStation
/
Press to enter or exit the patient information
management system.
10
F1
User-defined
key
You can assign a function to the key.
11
Biopsy
/
Press to show or hide the biopsy guide line.
12
Setup
/
Press to open/close the setup menu.
13
Del
/
Press to delete the comment, etc.
14
/
Alphanumeric
keys
Same as on PC
15
Dual
Dual-split screen
Press to enter Dual mode from non-Dual mode;
Press to switch between windows in Dual mode.
16
Arrow
/
Press to enter or exit the arrow comment status.
17
Cine
Cine Review
Press to enter or exit the Cine Review status.
18
/
Direction key
To adjust display brightness or contrast when pressing
with <Fn> key.
19
Steer
Press to open slant function for linear probe
20
Body Mark
/
Press to enter or exit the Body Mark status.
21
Comment
/
Press to enter or exit the character comment status.
22
Clear
/
Press to clear the comments or measurement calipers
on the screen.
23
Scale
/
Press to adjust the Scale value
24
Baseline
/
Press to adjust the baseline value
25
Nav.Rot
/
Multifunction knob
26
/
/
Press to implement the different function with
“Scale/Baseline/Nav.Rot” three keys.
