Product Specifications 2-3
No.
Name
Function
1
Probe holder
Sets the probe
2
Display
Displays the image and parameters
3
Control Panel
Man-machine interface for operation control, for details,
please refer to 2.1.2.1 Control Panel”.
4
Handle
For lifting the machine
5
IO Panel
Signal input / output panel, for details, please refer to “2.1.2.2
IO Panel”.
6
Power supply
panel
Signal input / output panel, for details, please refer to2.1.2.3
Power Supply Panel”.
7
Probe sockets
Sockets connecting probes and the main unit
8
Battery cover
Covering battery
9
USB ports
For connecting USB device (2 ports)
2.1.2.1 Control Panel
