Mindray Z6 Service Manual

Product Specifications 2-5
No.
Name
Description
Function
27
Cursor
/
Press to show the cursor.
28
Back
/
Press to return to the previous operation or to delete the
last project
29
/
Trackball
Roll the trackball to change the cursor position.
30
Set
/
Press to confirm an operation.
31
PW
/
Press to enter the PW mode
32
Color
/
Press to enter the color mode
33
M
/
Press to enter the M mode.
34
B
/
Press to enter the B mode
35
Measure
/
Press to enter/ exit Application Measurement
36
Update
/
Measurement status: press to switch between the fixed
and active end of the caliper;
Multi-imaging mode: press to change the currently active
window.
37
Caliper
/
Press to enter/ exit Measurement
38
Gain/
iTouch
/
Rotate: to adjust B or M gain
Press: to enter/ exit iTouch
39
TGC
/
Move to adjust time gain compensation.
40
Focus
Freq./THI
/
Press: to switch between Focus and Freq./THI;
Rotate: to adjust corresponding parameter
41
Depth
Zoom
/
Press: to switch between Depth and Zoom;
Rotate: to adjust corresponding parameter
42
Save 1
/
Press to save, user-defined key
43
Save 2
/
Press to save, user-defined key
44
Freeze
/
Press to freeze or unfreeze the image.
45
Print
/
Press to print: user-defined key.
46
/
Indicator 1
AC indicator
AC supply: light green;
Battery supply: light off.
47
/
Indicator 2
Battery status indicator
Charging: light in orange
Full: light in green
Discharge (electricity >20%): light in green
Discharge (electricity <20%): blinking in orange
Discharge (electricity <5%): blinking in orange
rapidly
Non-charge/ discharge: light off
