21 CARACTERISTICS OF THE MONITOR
21.1 DECLARATION OF CONFORMITY
Electromagnetic compatibility: The AVIOR-2 and MIP-2 have successfully passed the electromagnetic
compatibility (EMC) tests according to the EU directive: product standard NF-EN-55022, generic
standards NF-EN-50081-1 and NF -EN-50082-2.
AVIOR-2 and MIP-2 also comply with IEC 60846 and IEC 60325.
Full declarations of conformity are available upon request to:
MIRION TECHNOLOGIES (Canberra) SAS
BP249
ZI de Vauzelles
37602 Loches CEDEX
FRANCE
21.2 MECHANICAL CHARACTERISTICS
The housing of the AVIOR-2 and MIP-2 are made by polycarbonate injection. Very resistant, it is small,
easily decontaminable and waterproof.

Dimensions (W x H x l): 184 mm x 105 mm x 105 mm

Weight: 950 g including battery.
21.3 ENVIRONMENTAL CHARACTERISTICS
Environmental characteristics

Audible alarm: Greater than 85 dB (A) at 30 cm

Operating temperature: -20°C to + 50°C

Storage temperature: -25°C to + 60°C

Protection class: IP 54 according to IEC 60529

Vibration and shock: Complies with IEEE N42.17A and NF EN 60068-2-75 standards

Max operating altitude: 2000 m
21.4 ELECTRICAL CHARACTERISTICS
21.4.1 AVIOR-2

Power supply
x Mains (CEE 7/7 Plug and IEC 320 C13 socket): 100-240V 50/60 Hz, 300 my

Input / Output:
x USB mini plug
x 8-pin connector Measuring interface 1 and 2: CSP probe type
21.4.2 MIP-2

Power supply
x Mains (CEE 7/7 Plug and IEC 320 C13 socket): 100-240V 50/60 Hz, 300 my
