19 CONNECTOR INTERFACE 1 & 2 OF MIP-2
Interface 1 – NARDEUX Probe input
Signal
Pin
BIT 3 identification
1
BIT 2 identification
2
BIT 1 identification
3
BIT 0 identification
4
BF Signal 5
SAT Signal
6
+5V Power
7
BAT +12V power
8
BIT 4 identification
9
-12V Power
10
Ground
11
Ground
12
+12V power
13
Pulse Signal
14
Nardeux detection signal
15
Not Connected
16
Interface 2 – CSP Probe input
Signal
Pin
RXD Signal
1
TXD Signal
2
Ground
3
+5V Power
4
Pulse Signal
5
CSP detection signal
6
SCL (I2C)
7
SDA (I2C)
8
