14.2 HAND / FOOT
This function can only be accessed from the « Technician » user level (To change the user level, refer
to section 13.15).
Setting the Hand / Foot mode allows you to activate:
x double-sided measurement of the hands,
x auto integration time: activated, there is calculation of the measurement time. deactivated,
the measurement time is the one defined in the « Integration time » field,
x activation of the audible alarm at the end of the measurement.
Press the key to access the main menu 1.
Note: The line « Measure mode » is selected by default. If necessary press the keys or to
select the « Settings » line.
Press or to view the « Settings » screen.2.
Note: The line « Background noise » is selected by default. Use the keys or to select the
« Hand / Foot » line
Press the or key to display the « Hand / Foot » setting screen.3.
