Input / output:
x USB mini plug
x 16-pin connector measurement interface 1: Nardeux probe type
x 8-pin connector Measurement interface 2: CSP probe type
21.4.3 AVIOR-2 I/O & MIP-2 I/O
External power supply
x DC power supply: 24VDC, 500 mA
Inputs/Outputs :
x 5 relay outputs: NO, NC, 125 VAC, 60 VDC, 1A contacts
x 2 opto-coupled inputs: control voltage between 5VDC and 24VDC
x RS485 link: 2-wire MOD BUS
x +5 V output; 150 mA
x +24 V Input; 500 mA
x 3.5mm audio jack for 3-contacts headphones, 320 Ohm impedance, 100mW max power
21.4.4 AVIOR-2 battery
– Type: Lithium-ion,
– Capacity: 3.7V/5.3 Ah, 19.6W, max current 5A
– Charging time: less than 4 h.
– Performance of cycle of charge: 70% of the original capacity after 850 cycles of discharge at 100%
– Autonomy in measure ambient dose of 1 µGy/h including a period of 30 minutes in sound and visual
alarm without backlight:
x SBM-2D Probe CSP type = 67 hours.
– Autonomy in sound and visual alarm permanently without backlight:
x SBM-2D Probe CSP type = 15 hours.
21.4.5 MIP-2 battery
– Type: Lithium-ion,
– Capacity: 3.7V/5.3 Ah, 19.6W, max current 5A.
– Charging time: less than 4 h.
– Performance of cycle of charge: 70% of the original capacity after 850 cycles of discharge at 100%
– Autonomy in measure ambient dose of 1 µGy/h including a period of 30 minutes in sound and visual
alarm without backlight:
x SBM-2D Probe CSP type = 67 hours.
x SBM-2D Probe Nardeux type = 48 hours
– Autonomy in sound and visual alarm permanently without backlight:
x SBM-2D Probe CSP type = 15 hours.
x SBM-2D Probe Nardeux type = 14 hours.
