USER MANUAL
AVIOR-2/AVIOR-2 I/O & MIP-2/MIP-2 I/O
106491_C User manual AVIOR-2 MIP-2_En.docx
MIRION TECHNOLOGIES (Canberra)S.A.S, BP249, ZI de Vauzelles, 37602
In case of two probes connected, press or key to select "Interface 1" or "Interface 2"4.
line.
Note: For MIP-2, only interface 2 is compatible.
Press the or key to display the choice of control.5.
Note: The « Intermediate Control » line is selected by default
Press the or key to display the « Intermediate Control » menu.6.
Note: the activation of the measurement lock activates automatically the notification
To activate the notification of the expired control and / or block the measurement:
x Select the line with or ,
x Activate the box with the key ,
x Exit with the key and / or select another line to be modified with the or keys.
Press the key several times to return to the main menu.7.
