Mitel 6920 - XML Key; Configuring an XML Key Using the Mitel Web UI

82
C
ONFIGURING SOFTKEYS XML KEY
4. In the Line field, select a line number that is actively registered to the appropriate SIP proxy you are
using. Valid values are:
– global
– 1 through 24
NOTE: The Label and Valuefield are not required. The BroadWorks BLF/List name is config-
ured in the BLF List URIfield instead.
5. In the state fields, check (enable) or uncheck (disable) the states you want to apply to this softkey.
6. In the BLF List URI field, enter the name of the BLF list defined on the BroadSoft BroadWorks Busy
Lamp field page for your particular user. For example, sip:9@192.168.104.13.
NOTE: Contact your System Administrator for the BLF List URI.
Expansion Module Keys
7. Select from Key 1 through Key 84(M695).
8. In the Line field, select a line for which to apply this key. Valid values are:
– global
– 1 through 24
NOTE: The Value field is not required. The BroadWorks BLF/List name is configured in the BLF
List URI field instead.
9. In the BLF List URI field, enter the name of the BLF list defined on the BroadSoft BroadWorks Busy
Lamp field page for your particular user. For example, sip:9@192.168.104.13.
NOTE: Contact your System Administrator for the BLF List URI.
10. Click Save Settings.
XML Key
The 6920IP phone has a feature you can enable called XML (Extensible Markup Language). XML is a
markup language much like HTML. Your System Administrator can create customized XML menu
services and load them to your IP phone. These services include things like weather and traffic reports,
contact information, company info, stock quotes, or custom call scripts.
NOTE: The XML services must be set up by your System Administrator before you can use the key.
On the 6920 IP phone, you can access the XML applications from the IP phone UI via an XML softkey.
Using the Mitel Web UI, you can configure a key to access XML applications. Under Operations > Soft-
keys and XML, or Operations > Expansion Module, you can assign a key the type XML.
Configuring an XML Key Using the Mitel Web UI
1. Click on Operation > Softkeys and XML.
or
Click on Operation > Expansion Module <N>.
