About SMB Controller
CAUTION:
Be sure to observe the Safety Regulations.
4.
Remove the housing cover.
5.
Connect the earthing wire (see Earthing and protecting the communication server on page
60).
6.
Fit the housing cover.
7.
Secure the cage nuts in the appropriate positions in the rack's fastening rails (see Placing two
SMB Controllers above each other inside a 19" rack).
8.
Secure the SMB Controller to the rack's fastening rails using the M6 screws, the plastic
washers and the cage nuts.
9.
Fasten the snap-on tag to the front panel.
10.
Reconnect the SMB Controller to the power supply.
Installing the cable cover
Materials required:
•
Cable cover set
•
Screwdriver
To install the cable cover, proceed as follows:
1.
Pull off the screw covers on the left and right of the front panel.
2.
Use the M4 screws of the cable cover set to secure the brackets for the cable cover to the
SMB Controller.
Note:
The two brackets are not identical. Compare the cable brackets with the ones in
Installing the brackets for the cable cover.
Document Version 1.0
51 System Manual for Mitel SMB Controller
