MKS MF1 - Page 45

Chapter 4: USB Setup Interface
45
Controller Object [Controller]
28 156 0 3 NrOfInstances R uint8 1 - - -
28 156 0 4 ActInst RW uint8 1 1 1 -
28 28 1..n 0 SetpointF RW float 0 -1,00E+038 1,00E+038 NSTNV
28 28 1..n 1 SetpointI RW long 0
-
2147483647
2147483647 NSTNV
28 28 1..n 2 FlowUnit R uint8 0 0 15 NSTNV
28 28 1..n 3 FullScale R float 1 -1,00E+038 1,00E+038 NSTNV
28 28 1..n 4 Config RW uint8 0 0 2 STNV
28 28 1..n 5 SoftStartRate RW float 0 0 3600 STNV
28 28 1..n 6 SlewRate RW float 0 0 3600 STNV
28 28 1..n 7 SpHystLow RWPD float 1 0 5 STNV
28 28 1..n 8 SpHystHigh RWPD float 2 0 5 STNV
28 28 - 100 SetDefault WPF cmd - - - -
Sensor Object [Sensor]
Obj. Slot Inst. Param. Name Access Type Default Min. Max. Store
29 157 0 0 ObjId R uint8 29 - - -
29 157 0 1 ObjName R char[12] Sensor - - -
29 157 0 2 Length R uint16 8 - - -
29 157 0 3 NrOfInstances R uint8 1 - - -
29 157 0 4 ActInst RW uint8 1 1 1 -
29 29 1..n 0 FlowValue RW float 0
-
1,00E+006
1,00E+006 NSTNV
29 29 1..n 1 FullScaleN2 RWPF float 1 0.1 1,00E+009 STNV
29 29 - 100 SetDefault WPF cmd - - - -
Actuator (Valve) Object [Valve]
Obj. Slot Inst. Param. Name Access Type Default Min. Max. Store
30 158 0 0 ObjId R uint8 30 - - -
30 158 0 1 ObjName R char[12] Valve - - -
30 158 0 2 Length R uint16 6 - - -
30 158 0 3 NrOfInstances R uint8 1 - - -
30 158 0 4 ActInst RW uint8 1 1 1 -
30 30 1..n 0 ValvePosition R float 0 -1 100 NSTNV
30 30 1..n 1 ValveOverride RW uint8 0 0 2 NSTNV
30 30 1..n 2 ValveType RWPF uint8 1 0 1 STNV
30 30 - 100 SetDefault WPF cmd - - - -
Signal Processing Object [SigProc]
Obj. Slot Inst. Param. Name Access Type Default Min. Max. Store
31 159 0 0 ObjId R uint8 31 - - -
31 159 0 1 ObjName R char[12] SigProc - - -
