Chapter 5: Process Interface
80
Operation
Address
MODBUS compatible addressing description
The first 255 bytes of cyclic input and cyclic output data are available over the MODBUS
addressing. If the software address is < 248 in ASCII Modbus mode or < 99 in RTU Modbus mode,
the rotary switches are ignored and the software configurable address is used.
Note: The Address “Zero” is not supported and would cause a red ST LED.
Configuration
All Parameters for the communication are defined at the 'Com Interface Object' [ComIfc].
The delivery settings are:
Default settings
Parameter Modbus
Software Address 248
Baud Rate 9600
Parity 1 => even
Data Bits 8
Stop Bits 1
Failsave Timeout 0 (not used)
Config 1 => MODBUS compatible RTU
protocol
Configure the protocol.
0 Æ Human Readable Protocol, see RS485/USB Protocol
1 Æ MODBUS compatible RTU protocol
2 Æ MODBUS compatible ASCII protocol
Parity
Define the parity setup.
0 => none
1 => even
2 => odd
DataBits
Define the data bits. Possible values are for:
ASCII 7 or 8.
RTU 8.
StopBits
