MKS MF1 - Input Registers

Chapter 5: Process Interface
84
Example with the “Standard Input 1179 Object”
MODBUS Coil Address Parameter
1..2 ValveOverride
3 Autozero
4...6 ReportDiag (not used at Modbus)
7 WinkStatus
8 EnableTotalizer
9 ResetTotalizer
10 ResetStatus
11..14 SelectGasTable
15 EnGasCorrection
16 Not used
17...32 FlowSetpoint LSB (Byte 1 + 2)
33...64 FlowSetpoint MSB (Byte 3 + 4)
Input Registers
The address of the Input Register starts at 1.
The Input Registers are readable and not writable.
The Input Register represent the selected output object (default: Standard Output 1179 Object)
byte by byte.
One Input Register is an 16 bit Value and represent two bytes of the selected output object
