MKS MF1 - CAN Application Layer over Ethercat (Coe) - Objects

Chapter 5: Process Interface
90
OverTemperature 0x34f3 0 USINT
ValveDriveAlarm 0x34f4 0 USINT
CalibrationRecommended 0x34f5 0 USINT
Uncalibrated 0x34f6 0 USINT
ControllerError 0x34f7 0 USINT
MemoryFailure 0x34f8 0 USINT
UnexpectedCondition 0x34f9 0 USINT
ThermalMassFlowRate 0x34fa 0 DINT
InternalTemperature 0x34fb 0 DINT
ValveDriveLevel 0x34fc 0 DINT
RxPdo (0x1600) - Available RxPDOs of the MF1
Name Index SubIndex DataType
ValveOverride 0x33ed 0 USINT
Autozero 0x33ee 0 USINT
ReportDiag 0x33ef 0 USINT
WinkStatus 0x33f0 0 USINT
EnableTotalizer 0x33f1 0 USINT
ResetTotalizer 0x33f2 0 USINT
ResetStatus 0x33f3 0 USINT
SelectGasTable 0x33f4 0 USINT
EnGasCorrection 0x33f5 0 USINT
FlowSetpoint 0x33f6 0 DINT
CAN application layer over EtherCAT (CoE) - Objects
The standard object dictionary is implemented according to the DS301 communication profile
(Index 0x1000 - 0x1c33).
Index Name
Sub-
Index Description DataType Access Comment
0x1000 Device type 0 Device type UDINT ro
0x00000000 (No
profile)
0x1001 Error register 0 Error register USINT ro
Pre-defined error
field 0 Number of errors USINT rw
0x1003
1 … 5 Number of errors UDINT ro
0x1008 Device name 0 Device name
STRING(11
) ro
Restore default
parameters 0
Largest sub index
supported USINT ro
0x1011 1
Restore all default
parameters UDINT rw
