MKS MF1 - Error Codes; Feedback and Diagnostics; LED Functions

Chapter 5: Process Interface
82
Rounding the CD to an integer and calculate now the error
.
⎟
⎠
⎞
⎜
⎝
⎛
∗∗
−∗=
48054857
16
1100
CDudRateExpectedBa
Error
Feedback and Diagnostics
Error Codes
Standard Modbus Error codes are used.
LED Functions
LED Functions
Item Detail Description
Off No power or not initialized
Green Initialized
ST
Red Communication Error
Off No power, not initialized
Green Initialized
Flashing green Data exchange
Red Timeout error
OP
Flashing red Timeout error, data exchange
Green Sensor OK
Flashing red Power too low
Blue Pure USB operation
Flashing red & green Self Test or Boot
SI
Flashing blue Shows Seconds for AUTOZERO button
Off No flow
Flashing blue Flow Indicator: Flashes proportional to actual flow
FL
Blue on 100% Flow
