MKS MF1 - Default Settings; Objects; Object Model; Object Parameters Description

Chapter 4: USB Setup Interface
29
• the response for setting or the actual value will be returned:
> Value <CR>
• in case off error, e.g. wrong type or not existing name a code is returned:
! Code <CR>
• Command:
* CommandName <CR>
Note
It is possible to power the MFC electronic only via the USB interface,
which enables the check or the update of the settings, but not the
operation of the MFC. The Profibus board require the 24 VDC supply to
be powered up, so changes on the Profibus address would be updated
only when the MFC is connected to a 24 VDC power supply.
Default settings
Objects
Object Model
All parameters of the device reside in objects.
Object Reference
Object Definitions are documented in the Object Reference. Actual Values of the parameters are
available in REPORT.HTM on the MSD drive.
Object Parameters Description
Object Parameters for all Objects [*; ObjId=*]
Name
Par.
Type
Description
ObjId Inst ID of Object
ObjName Inst Short Name of Object
Length Inst Byte size of Object
NrOfInstances Inst Numbers of Instances
ActInst Inst choose the actual Instance (e.g. used for Profibus)
Standard Input 1179 Object [SmallRecv; ObjId=20]
Name
Par.
Type
Description
ValveOverride Inst see Valve - ValveOverride
Autozero Inst see Meter - AutoZero
ReportDiag Inst changing generate a 6 byte Profibus Diagnostic
WinkStatus Inst 0 to 1 transition sets the blue LED to blinking for 5 sec
EnableTotalizer Inst see Meter - EnableTotalizer
ResetTotalizer Inst see Meter - ResetTotalizer
