MKS MF1 - Object Parameter Reference

Chapter 4: USB Setup Interface
40
Alias Params Object [AliasParams; ObjId=45]
Name
Par.
Type
Description
AliasObjectInstance Inst TBD
SourceObjectId Inst TBD
SourceAttributeId Inst TBD
Object Parameter Reference
Standard Input 1179 Object [SmallRecv]
Obj. Slot Inst. Param. Name Access Type Default Min. Max. Store
20 148 0 0 ObjId R uint8 20 - - -
20 148 0 1 ObjName R char[12] SmallRecv - - -
20 148 0 2 Length R uint16 6 - - -
20 148 0 3 NrOfInstances R uint8 1 - - -
20 148 0 4 ActInst RW uint8 1 1 1 -
20 20 1..n 0 ValveOverride RW uint:2 1 0 2 NSTNV
20 20 1..n 1 Autozero W uint:1 0 0 1 NSTNV
20 20 1..n 2 ReportDiag W uint:3 0 0 3 NSTNV
20 20 1..n 3 WinkStatus W uint:1 0 0 1 NSTNV
20 20 1..n 4 EnableTotalizer RW uint:1 0 0 1 NSTNV
20 20 1..n 5 ResetTotalizer W uint:1 0 0 1 NSTNV
20 20 1..n 6 ResetStatus W uint:1 0 0 1 NSTNV
20 20 1..n 7 SelectGasTable RW uint:4 15 0 15 NSTNV
20 20 1..n 8 EnGasCorrection RW uint:1 0 0 1 NSTNV
20 20 1..n 9 FlowSetpoint RW long 0
-
2147483647
2147483647 NSTNV
20 20 - 100 SetDefault W cmd - - - -
20 20 - 101 Autozero W cmd - - - -
20 20 - 102 ResetAutozero W cmd - - - -
20 20 - 103 Wink W cmd - - - -
20 20 - 104 ResetTotalizer W cmd - - - -
Standard Output 1179 Object [SmallSend]
Obj. Slot Inst. Param. Name Access Type Default Min. Max. Store
21 149 0 0 ObjId R uint8 21 - - -
21 149 0 1 ObjName R char[12] SmallSend - - -
21 149 0 2 Length R uint16 14 - - -
21 149 0 3 NrOfInstances R uint8 1 - - -
21 149 0 4 ActInst RW uint8 1 1 1 -
21 21 1..n 0 HighLimitAlarm R uint:1 0 0 1 NSTNV
21 21 1..n 1 LowLimitAlarm R uint:1 0 0 1 NSTNV
21 21 1..n 2 SystemError R uint:1 0 0 1 NSTNV
