Chapter 4: USB Setup Interface
41
Standard Output 1179 Object [SmallSend]
21 21 1..n 3 High2LimitAlarm R uint:1 0 0 1 NSTNV
21 21 1..n 4 Low2LimitAlarm R uint:1 0 0 1 NSTNV
21 21 1..n 5 ValveClosed R uint:1 0 0 1 NSTNV
21 21 1..n 6 Purge R uint:1 0 0 1 NSTNV
21 21 1..n 7 OverTemperature R uint:1 0 0 1 NSTNV
21 21 1..n 8 ValveDriveAlarm R uint:1 0 0 1 NSTNV
21 21 1..n 9 CalibrationRecommended R uint:1 0 0 1 NSTNV
21 21 1..n 10 Uncalibrated R uint:1 0 0 1 NSTNV
21 21 1..n 11 ControllerError R uint:1 0 0 1 NSTNV
21 21 1..n 12 MemoryFailure R uint:1 0 0 1 NSTNV
21 21 1..n 13 UnexpectedCondition R uint:1 0 0 1 NSTNV
21 21 1..n 14 ThermalMassFlowRate R long 0
-
2147483647
2147483647 NSTNV
21 21 1..n 15 InternalTemperature R long 0
-
2147483647
2147483647 NSTNV
21 21 1..n 16 ValveDriveLevel R long 0
-
2147483647
2147483647 NSTNV
21 21 - 100 SetDefault WPF cmd - - - -
Full Output 1179 Object [FullSend]
Obj. Slot Inst. Param. Name Access Type Default Min. Max. Store
22 150 0 0 ObjId R uint8 22 - - -
22 150 0 1 ObjName R char[12] FullSend - - -
22 150 0 2 Length R uint16 18 - - -
22 150 0 3 NrOfInstances R uint8 1 - - -
22 150 0 4 ActInst RW uint8 1 1 1 -
22 22 1..n 0 HighLimitAlarm R uint:1 0 0 1 NSTNV
22 22 1..n 1 LowLimitAlarm R uint:1 0 0 1 NSTNV
22 22 1..n 2 SystemError R uint:1 0 0 1 NSTNV
22 22 1..n 3 High2LimitAlarm R uint:1 0 0 1 NSTNV
22 22 1..n 4 Low2LimitAlarm R uint:1 0 0 1 NSTNV
22 22 1..n 5 ValveClosed R uint:1 0 0 1 NSTNV
22 22 1..n 6 Purge R uint:1 0 0 1 NSTNV
22 22 1..n 7 OverTemperature R uint:1 0 0 1 NSTNV
22 22 1..n 8 ValveDriveAlarm R uint:1 0 0 1 NSTNV
22 22 1..n 9 CalibrationRecommended R uint:1 0 0 1 NSTNV
22 22 1..n 10 Uncalibrated R uint:1 0 0 1 NSTNV
22 22 1..n 11 ControllerError R uint:1 0 0 1 NSTNV
22 22 1..n 12 MemoryFailure R uint:1 0 0 1 NSTNV
22 22 1..n 13 UnexpectedCondition R uint:1 0 0 1 NSTNV
22 22 1..n 14 ThermalMassFlowRate R long 0
-
2147483647
2147483647 NSTNV
22 22 1..n 15 InternalTemperature R long 0
-
2147483647
2147483647 NSTNV
22 22 1..n 16 ValveDriveLevel R long 0
-
2147483647
2147483647 NSTNV
