MKS MF1 - Page 42

Chapter 4: USB Setup Interface
42
Full Output 1179 Object [FullSend]
22 22 1..n 17 FlowTotalized R long 0
-
2147483647
2147483647 NSTNV
22 22 - 100 SetDefault WPF cmd - - - -
Standard Setup 1179 Object [SmallSetup]
Obj. Slot Inst. Param. Name Access Type Default Min. Max. Store
23 151 0 0 ObjId R uint8 23 - - -
23 151 0 1 ObjName R char[12] SmallSetup - - -
23 151 0 2 Length R uint16 80 - - -
23 151 0 3 NrOfInstances R uint8 1 - - -
23 151 0 4 ActInst RW uint8 1 1 1 -
23 23 1..n 0 BaseUnit RW uint:1 0 0 1 STNV
23 23 1..n 1 OperationMode RW uint:1 0 0 1 STNV
23 23 1..n 2 ZeroGain RW long 1000000 50000 2000000 STNV
23 23 1..n 3 ZeroOffset RW long 0 -50000 50000 STNV
23 23 1..n 4 TripPointHigh RW long 0 -100000 1200000 STNV
23 23 1..n 5 TripPointLow RW long 0 -100000 1200000 STNV
23 23 1..n 6 GasCorrection RW long 10000 100 100000 STNV
23 23 1..n 7 DefaultTable RW uint8 0 0 15 STNV
23 23 1..n 8 TripPointHigh2 RW long 0 -100000 1200000 STNV
23 23 1..n 9 TripPointLow2 RW long 0 -100000 1200000 STNV
23 23 1..n 10 FilterSettling RW long 0 0 10000000 STNV
23 23 1..n 11 SoftStartRate RW long 0 0 36000000 STNV
23 23 1..n 12 TimeToCal RW uint16 0 0 65535 NSTNV
23 23 1..n 13 CalDate RW char[7] 10108 - - STNV
23 23 1..n 14 UserTag RW char[32] - - STNV
23 23 - 100 SetDefault WPF cmd - - - -
Standard Diagnostic Object [SmallDiag]
Obj. Slot Inst. Param. Name Access Type Default Min. Max. Store
24 152 0 0 ObjId R uint8 24 - - -
24 152 0 1 ObjName R char[12] SmallDiag - - -
24 152 0 2 Length R uint16 48 - - -
24 152 0 3 NrOfInstances R uint8 1 - - -
24 152 0 4 ActInst RW uint8 1 1 1 -
24 24 1..n 0 CommonExceptionDetailAlarm R uint8 0 0 255 NSTNV
24 24 1..n 1 DeviceExceptionDetailAlarm R uint8 0 0 255 NSTNV
24 24 1..n 2 ManufacturerExceptionDetailAlarm R uint8 0 0 255 NSTNV
24 24 1..n 3 CommonExceptionDetailWarn R uint8 0 0 255 NSTNV
24 24 1..n 4 DeviceExceptionDetailWarn R uint8 0 0 255 NSTNV
24 24 1..n 5 ManufacturerExceptionDetailWarn R uint8 0 0 255 NSTNV
24 24 1..n 6 ProductCode R char[8] MF1 - - NSTNV
24 24 1..n 7 SoftwareRevision R char[8] 01.01.00 - - NSTNV
