MKS MF1 - Page 43

Chapter 4: USB Setup Interface
43
Standard Diagnostic Object [SmallDiag]
24 24 1..n 8 HardwareRevision R char[8] 01.01.00 - - NSTNV
24 24 1..n 9 FullScale R long 1
-
2147483647
2147483647 NSTNV
24 24 1..n 10 RunHours R long 0 0 2000000000 NSTNV
24 24 1..n 11 InternalTemp R float 0 0 120 NSTNV
24 24 1..n 12 ValvePosition R float 0 0 110 NSTNV
24 24 1..n 13 TimeToCal R uint16 0 0 65535 NSTNV
24 24 - 100 SetDefault WPF cmd - - - -
Identity Object [Identity]
Obj. Slot Inst. Param. Name Access Type Default Min. Max. Store
25 153 0 0 ObjId R uint8 25 - - -
25 153 0 1 ObjName R char[12] Identity - - -
25 153 0 2 Length R uint16 257 - - -
25 153 0 3 NrOfInstances R uint8 1 - - -
25 153 0 4 ActInst RW uint8 1 1 1 -
25 25 1..n 0 DeviceType R char[8] MFC - - STNV
25 25 1..n 1 ProductCode RWPF char[8] MF1 - - STNV
25 25 1..n 2 Manufacturer R char[16] MKSI - - STNV
25 25 1..n 3 Model RWPF char[32] MF1 - - STNV
25 25 1..n 4 SerialNumber RWPF char[16] 123456 - - STNV
25 25 1..n 5 SoftwareRevision R char[8] 01.01.00 - - STNV
25 25 1..n 6 HardwareRevision RWPF char[8] 01.01.00 - - STNV
25 25 1..n 7 InterfaceType R char[21] - - STNV
25 25 1..n 8 SensorType RWPF char[21] - - STNV
25 25 1..n 9 SpecialNr RWPF uint16 0 0 65535 STNV
25 25 1..n 10 CalDate RW char[7] 10109 - - STNV
25 25 1..n 11 UserTag RW char[32] user - - STNV
25 25 1..n 12 SvnNr R long 0 0 2147483647 STNV
25 25 1..n 13 SibSNr R char[16] X - - STNV
25 25 1..n 14 DibSNr R char[16] X - - STNV
25 25 1..n 15 DibFwVersion R char[21] X - - STNV
25 25 1..n 16 CdcName R char[13] MF1 - - STNV
25 25 1..n 17 CdcRevision R char[8] 01.01.00 - - STNV
25 25 - 100 SetDefault WPF cmd - - - -
Password Object [Password]
Obj. Slot Inst. Param. Name Access Type Default Min. Max. Store
26 154 0 0 ObjId R uint8 26 - - -
26 154 0 1 ObjName R char[12] Password - - -
26 154 0 2 Length R uint16 53 - - -
26 154 0 3 NrOfInstances R uint8 1 - - -
