Identity 0 Identity USINT ro
1 Vendor ID UDINT ro
2 Product Code UDINT ro
3 Revision Number UDINT ro
0x1018
4 Serial Number UDINT ro
No. of mapped application
DO RxPDO-Map 0
objects in PDO
USINT ro
No. of mapped
objects (0.. 254)
0x1600
1 … n Mapped object 1 … n UDINT ro
No. of mapped application
DI TxPDO-Map 0
objects in PDO
USINT ro
No. of mapped
objects (0.. 254)
0x1a00
1 … n Mapped object 1 … n UDINT ro
Sync manager type 0 Number of entries USINT ro 4
1 Mailbox wr USINT ro 1
2 Mailbox rd USINT ro 2
3 Process Data out USINT ro 3
0x1c00
4 Process Data in USINT ro 4
RxPDO assign 0 No. of assigned PDOs USINT ro 1
0x1c12
1 Assigned PDO UINT ro 0x1600
TxPDO assign 0 TxPDO assign USINT ro
0x1c13
1 Assigned PDO UINT ro 0x1A00
SM output
parameter 0 Number of entries USINT ro 1
0x1c32
1 Sync mode UINT ro 0 (FREE_RUN)
SM input parameter 0 Number of entries USINT ro 1
0x1c33
1 Assigned PDO UINT ro 0 (FREE_RUN)
0x33ED ValveOverride 0 ValveOverride USINT rw
[normal, Valve
Close, Valve
Purge]
0x33EE Autozero 0 Autozero USINT rw
0 to 1 transition
activates zeroing
if
(VALVE_OVER
RIDE==FLOW_
OFF &&
FLOW_SETPOI
NT < 5%FS)
0x33EF ReportDiag 0 ReportDiag USINT rw Not used
0x33F0 WinkStatus 0 WinkStatus USINT rw
0 to 1 transition
sets the blue
LED to blinking
for 5 sec
0x33F1 EnableTotalizer 0 EnableTotalizer USINT rw
enable the
totalizer funktion
0x33F2 ResetTotalizer 0 ResetTotalizer USINT rw
see Meter -
ResetTotalizer
0x33F3 ResetStatus 0 ResetStatus USINT rw
0 to 1 transition
resets totalizer to
zero
