Motorola solutions MTP3100 User Manual

No. Part/Kit Number Description Remark
0104065J29
13
Front housing assembly with Bluetooth anten-
na
Not serviceable. Compris-
es of 0104042J37, item
#5, 9, 17, and 18.
20 PMHN4172_Z
12
Front housing hardware kit without Bluetooth
antenna
Serviceable. Comprises of
55012012001 and item
#19.
PMHN4173_Z
12
Front housing hardware kit with Bluetooth an-
tenna
Serviceable. Comprises
of 0104042J37 and item
#19.
PMHN4293_Z
13
Front housing hardware kit with Bluetooth
PMHN4294_Z
13
Front housing hardware kit without Bluetooth
antenna
Serviceable. Comprises of
55012012001 and item
#19.
PMHN4310_Z Front housing hardware kit with Bluetooth vi-
brator, MTP3500
Serviceable. Comprises
of 0104042J37 and item
#19.
21 75012091001
12
Thermal pad Serviceable. Replace with
a new thermal pad if
found cracked/torn.
BU000063A01
12,
13
Thermal pad, MTP3500
22 32012177001 Control top seal Serviceable.
23 0375375A01 Screw M2.0
24 Refer to Table
43: Service Re-
placement Kit Ma-
trix for Mainboard
(EMEA) on page
134.
Main board kit
25 42012039002 Bottom connector locking retainer
26 0104042J09 Bottom connector flex assembly
27 03012039001
13
Screw M2.5, MTP3500
03012039002
12
Screw M2.5
28 15012128001
12
Back cover
15012128002
13
Back cover, MTP3500
29 32012139001 RF switch seal
30 32012124001
12
Battery connector seal
SL000220A01
13
Battery connector seal, MTP3500
31 32012135001 Main O-ring Serviceable. Replace with
a new main O-ring after
servicing.
32 36012016002 Volume knob (by default) Serviceable.
36012029001 RFID knob (offered as an option through DC)
33 36012017002 Frequency knob
34 85012034001
14
Antenna stubby 350–390 MHz
68015000841-EL
Chapter 5: Maintenance
89
