No. Part/Kit Number Description Remark
85012031001 Antenna whip 380–430 MHz
85012033001 Antenna stubby 380–430 MHz
85012056001
AN000251A0
15
85012065001 Antenna whip 410–470 MHz
85012066001 Antenna short stubby 410–470 MHz
85012069001
11,
14
Antenna stubby 806–870 MHz
85012070001
11,
14
Antenna whip 806–870 MHz
35 54012165001 Ventilation label Serviceable. Replace to-
gether with item #36.
36 3286058L01 Gore port Serviceable. Replace to-
gether with item #35.
37 0104045J11
10, 11,
12, 16
Back chassis assembly (SIM) Serviceable.
0104054J35
12
Back chassis assembly (Plain)
0104064J82
13
Back chassis assembly (SIM), MTP3500
0104064J83
13
Back chassis assembly (Plain), MTP3500
38 030120360014 Screw M1.4
39 550120110022
16
SIM door catch
550120110023
16
40 150121120012 SIM door
150121120013
150121120014
41 320121190012 SIM door O-ring
320121190013
320121190014
42 750121670012 SIM door pad Not serviceable. Order to-
gether with item #40.
750121670013
750121670014
43 130120290012 SIM door escutcheon Serviceable.
130120290013
130120290014
14
Available in APAC region.
15
Replacement of 85012056001 after inventory depletes.
16
Not offered for 800 MHz radio models.
68015000841-EL
