4 Product Description
22 Rev. 03/2019
Feature Value
Number of outputs MIC5:
20 outputs
MIC5-SE:
8 outputs
Firing Angles The size of the firing angle depends on the max. overspeed. The
smallest firing angle per output bank can be calculated using the
following formula:
Ignition frequency MIC5:
With full energy output (all 20 ignition outputs with 500 mJ), an
ignition frequency of 300 Hz as continuous load is possible. With
less ignition energy or in case of a brief overload, 360 Hz is
possible. The maximum output load of 180 W must not be
exceeded.
MIC5-SE:
With full energy output (all 8 ignition outputs with 500 mJ), an
ignition frequency of 120 Hz as continuous load is possible. With
less ignition energy or in case of a brief overload, 150 Hz is
possible. The maximum output load of 75 W must not be
exceeded.
2-stroke engine:
4-stroke engine:
Output connector MIC5:
35-pole military connector
MIC5-SE:
17-pole military connector
