4 Product Description
Rev. 03/2019 23
Estimation of Current Requirements
These current values are based on a nominal speed of 1800 rpm and 500 mJ energy
MIC5:
Outputs Voltage Required current Voltage Required current
10 24 V 5 A 16 V* 7 A
16 24 V 7 A 16 V* 11 A
20 24 V 9 A 16 V* 14 A
* Nominal voltage 24 V DC
MIC5-SE:
Outputs Voltage Required current
8 24 V 4 A
Electrical Data for Inputs and Outputs
The inputs and outputs of the ignition controller have the following electrical data:
Inputs and outputs Values
Analog current input Current range: 0 mA to 20 mA (adjustable in MICT)
Input impedance: 27 || 1 µF
Analog voltage input Voltage range: 0 mA to 10 mA (adjustable in MICT)
Input impedance: 12.4 k || 200 nF
Auxiliary analog input
supply voltage
5 V to 24 V/50 mA depending on the configuration in the MICT
Binary input (Start/Stop) Wiring
Input current: max. 20 mA
Ignition stop: 0 V to 0.8 V (low level)
Ignition release: 2.8 V to 32 V (high level)
Binary input (schedule A/B) Wiring
Input current: max. 20 mA
Schedule A: 0 V to 0.8 V (low level)
Schedule B: 2.8 V to 32 V (high level)
