6 Wiring of the Device
44
Rev. 03/2019
Two-Wire Transm
itter
Four-Wire Transmitter
Auxiliary anal
og input supp
ly voltage
An auxiliary supply voltage for
the analog inputs can be configured using
the MICT. The voltage can be set in the range of 5 to 24 V and is made
available on the connection
Analog Power
. Please refer to the section
Timing – Analog Inputs
on page
100.
43
45
