4 Product description
Maschinenfabrik Reinhausen GmbH 202046 6385142/08 ENETOS
®
ED
Figure26: Apparent power, oil level, and ambient temperature
1 Asset intelligence 2 Total apparent power
3 Ambient temperature 4 Oil level (transformer on left, on-
load tap-changer on right)
Figure27: On-load tap-changer and motor-drive unit
1 OLTC oil temperature 2 Current tap position
3 Voltage regulator 4 Tap-change operation statistics
5 OLTC status message (collective
message)
