10 Messages
Maschinenfabrik Reinhausen 2014150 222/08 ENTAPCON® 240
Messages
This chapter contains an overview of the device's messages.
Signal inputs
Input Inscription Function
IO-X1:28 MOTOR-DRIVE
UNIT IN OPERA-
TION
Motor-drive unit is in operation
IO-X1:29 MOTOR PROTEC-
TIVE SWITCH OFF
Motor protective switch has trig-
gered
IO-X1:31
IO-X1:33
CAN BE FREELY
PARAMETERIZED
0:OFF
1:MASTER_FOLLOWER
2:LOCAL_REMOTE
3:REGULATOR_BLOCKING
4:LV_HIGH-
SPEED_TAP_CHANGES
5:MOTOR_PROTEC-
TIVE_SWITCH_TRIGGERED
6:REMOTE
IO-X1:12 AUTO Activate AUTO mode
IO-X1:11 MANUAL Activate MANUAL mode
IO-X1:13 RAISE Raise tap position
IO-X1:14 LOWER Lower tap position
UC-
X1:14...17,
UC-
X1:14...18,
UC-X1:30...33
BCD1…BCD10 BCD tap input signal
UC-X1:11 PARALLEL GROUP
1
Assign parallel operation group 1
UC-X1:12 PARALLEL GROUP
2
Assign parallel operation group 2
Table 42: Signal inputs
