12 Overview of parameters
Maschinenfabrik Reinhausen 2014154 222/08 ENTAPCON® 240
Overview of parameters
This section contains an overview of the relevant menus and parameters.
Parameter Setting range Factory setting Current setting
Parameter > Normset
Normset activation On/Off Off
Primary voltage 0...9999 kV 0 kV
Secondary voltage 57...125 V 100 V
Desired value 1 49...140 V 100 V
Parameter > Control parameter
Bandwidth 0.5...9 % 1.00 %
Power-dependent desired
value
On/Off Off
Max. power-dependent de-
sired value
49...140 V 105.0 V
Min. power-dependent de-
sired value
49...140 V 95.0 V
Desired value 1 49...140 V 100.0 V
Desired value 2 49...140 V 100.0 V
Desired value 3 49...140 V 100.0 V
Desired value at 0 active
power
49...140 V 100.0 V
T1 control response T1 linear/T1 integral T1 linear
T1 delay time 0...600 s 40 s
T2 activation T2 on/T2 off T2 off
T2 delay time 1...60 s 10.0 s
Active power at max. desired
value
0.1...1000 MW 10.0 MW
Active power at min. desired
value
-1000...-0.1 MW -10.0 MW
Parameter > Limit values
Fct. Monitoring On/Off Off
Absolute limit values On/Off Off
I> Overcurrent 50...210 % 110 %
Max. operations in time 0...20 0
Tap max. -128...128 128
Tap min. -128...128 -128
T block max. number of
steps
0...600 s 0 s
Lower -> reset raise cnt. On/Off Off
U< Blocking On/Off On
U< Undervoltage (%) 60...100 % 90 %
U< Undervoltage (V) 34...160 V 90.0 V
