12 Overview of parameters
Maschinenfabrik Reinhausen 2014 155222/08 EN TAPCON® 240
Parameter Setting range Factory setting Current setting
U< Delay 0...20 s 10.0 s
U< also under 30 V On/Off Off
U> Overvoltage (%) 100...140 % 110.0 %
U> Overvoltage (V) 34...160 V 110.0 V
Time slice for steps 0...1800 s 0 s
Parameter > Compensation
Ur line drop comp. -25...25 V 0.0 V
Ux line drop comp. -25...25 V 0.0 V
Z comp. limit value 0...15 % 0.0 %
Z compensation 0...15 % 0.0 %
Parameter > Cross-monitoring
Error message 0...10 s 10 s
U prim. regulator 2 0...9999 kV 0 kV
U sec. regulator 2 57...125 V 100.0 V
U< regulator 2 34...160 V 60.0 V
U< regulator 2 60...100 % 60 %
U> regulator 2 34...160 V 140.0 V
U> regulator 2 100...140 % 140 %
U ref for regulator 2 49...140 V 100.0 V
Configuration > Transformer data
Primary voltage 0...9999 kV 0 kV
Primary current 0...9999 A 0 A
Secondary voltage 57...125 V 100.0 V
Current transformer connec-
tion
Unknown; 0.2 A; 1 A;
5 A
Unknown
Transformer circuit See [► 101] 0 1PH
Configuration > General
Display %/ A On/Off Off
Display dark On/Off On
Display kV / V kV/V V
COM1 setting 9.6 kilobaud; 19.2 kilo-
baud; 38.4 kilobaud;
57.6 kilobaud
57.6 kilobaud
R/L pulse duration 0...10 s 1.5 s
IO1-X1:23/24 See [► 59] Desired value 3
IO1-X1:25/26 See [► 59] Desired value 2
IO1-X1:31 See [► 58] Off
IO1-X1:33 See [► 58] Off
Motor runtime 0...30 s 0.0 s
Regulator ID - 0000
Language See [► 42] English
